生化学検査免疫検査
検体搬送システム VITROS™ Automation Solutions
Item 1 of 3
特長
- 01
- 到着確認から結果承認までフルオートメーション、検査前後の単純作業を軽減します。
- 02
- ウォーターレスシステムのビトロス™ ならではの コンパクトで自由度の高いレイアウトをご提案します。
- 03
- 搬送システムに架けられた検体に対して効率的なルーティング（インテリジェント ルーティング） とトラッキング（追跡）を行います。一本搬送の特長を活かし、搬送中の検体ルート変更も臨機 応変に対応します。
- 04
- 検体架設から最終報告までの検査プロセスを管理し、 その時点での最適な検査工程をシステムで瞬時に考え自動で分析機毎へ検体を割振ります。
製品概要
中小規模病院および大規模（夜間緊急検査用）に対応可能なVITROS Automation Solutionsは、検体搬送システムとミドルウェアにビトロス™ を組み合わせることが可能です。
ウォーターレスシステムのビトロス™ ならではの コンパクトで自由度の高いレイアウトが可能です。
VITROS Automation Solutionsによる効果
・自動化によるヒューマンエラーの防止
・効率的な検体動線の構築
・生産性向上による人材育成、タスクシフト/シェアの推進
・機器バックアップ体制
仕様・スペック
| 搬送工程管理 | 依頼項目・採血管キャップの有無・各分析装置の搭載項目・試薬残量・分析装置の負荷状況・緊急検体・希釈スタート（前回値確認） |
|---|---|
| 測定工程管理 | ビトロス™ インテリチェック™ 機能による測定プロセス一連のモニタリング |
| 再検ロジック | 自動再検・希釈倍率設定・条件追加依頼など |
| 検査後工程管理 | 検体仕分け、検体保管、検体検索取出し指示 |
| 自動運行管理 | 分析装置・モジュールの状態を常に把握し、最適な検体搬送を行う( 分析装置自動復旧) |
